PB9600SD Super Duty Platform/Stake Body

PB9600SD Super Duty Platform/Stake Body

Introducing our Super Duty Platform/Stake Body – the ultimate in heavy-duty construction and reliability. Crafted with only the highest quality materials and meticulous attention to detail, this truck bed is engineered to handle the toughest of jobs with ease. The bed features robust exterior stake pockets, and 4″ structural cross members spaced 12″ apart, providing unbeatable support for even the heaviest loads. The bed is finished with 2 coats of Imron® Polyurethane High Gloss DTM for maximum protection against harsh weather and wear and tear. With our Super Duty Platform Truck Bed, you can rest assured that you have the most rugged and dependable tool for any job.

Specifications

Lengths

12'6", 14'6", 16'6", 18'6", 20'6", 22'6", 24'6", 26'6"

Outside Width

96" (optional 102" wide)

Floor Width

91 3/4" (optional 97 3/4"" wide)

Weight Range

2117-4118

Standard Features

  • Structural channel long sills
    • 12’6″ – 18’6″ – 7″ × 9.8 lb Channel
    • 20’6″ – 26’6″ – 8″ x 11.5 lb Channel
  • 4″ structural cross members, 12″ o.c.
  • 7 ga. formed rear rail
  • 7 ga. smooth steel, diamond plate, KDAT pine, or other options available. Call for details
  • Heavy duty exterior stake pockets 24″ o.c. with 3/8″ × 3″ rub rail on sides and rear.
  • 48″ weld-on 10 ga. bulkhead with single screen window, 3 x 2 tube uprights and formed trapezoid top rail
  • 3/4″ LED marker & clearance lights with rubber grommets and wire harness.
  • Sand blasted and painted with 2 coats of Imron® 3.1 HG-D + Polyurethane High Gloss DTM

Stake Racks

  • Stake racks constructed with 10 ga. reinforced stakes
  • 16 ga. roll formed slats or ¾” black poly slats
  • Spring loaded latch system on stakes insure assure secure attachment to body.
  • Standard size 42″ high with 4 slats, includes rack latches. (other sizes available)
  • (Optional) Rear swing out racks with bolt-on rear post
  • Rack weight per 4′ section 4 slat × 42″ high, 49 lbs.
  • Sand blasted and painted with 2 coats of Imron® 3.1 HG-D™M + Polyurethane High Gloss DTM

Available Options

  • 1/4″ Steel Floor
  • Red Oak Floor
  • Apitong Hardwood Flooring
  • 102″ overall width
  • 54″ or 60″ Super Duty Bulkhead
  • Triple Window in Bulkhead
  • Rear Pintle Hitch Plate
  • Rear Reese Hitch
  • Gooseneck Hitch
  • Full Rear Light Skirt w/2 oval stop/turn/tail lights and 1 reverse per side plus marker, clearance and license plate light with wiring harness
  • 18″, 24″, 36″ or 48″ Cab Shield
  • ICC Bumper
  • Dump Hoist – Electric or PTO
  • Custom Sizes
